Features:
-
Excellent water resistance and pumpability.
-
Wide operating temperature range: performs well at low temperatures and does not flow at high temperatures.
-
Improves switch contact lubrication and reduces copper wear.
-
Made entirely from synthetic oils; non-corrosive to metal materials.
-
Low volatility; remains soft and effective during long-term use.
-
High oxidation resistance for long-lasting lubrication.
Packaging:
-
1 kg / can (6 kg / carton)
Storage Instructions:
-
Seal the can after use to prevent contamination.
-
Store in a cool, dry place.
-
Keep away from oxidizers, strong acids, and alkaline substances.
Limited Warranty Information – Please Read Carefully:
The information provided herein is accurate to the best of our knowledge. However, because the conditions and methods of use are beyond our control, this information cannot replace the testing conducted by the customer to ensure the product’s safety, effectiveness, and suitability for a specific end-use. Our usage recommendations should not be considered as a guarantee against infringement of any patents.
For contacts and contact points in various types of switches, including rocker switches, rotary switches, and push-button switches.
Technical Parameters of Contact Grease EC8
Test Item |
Measured Value |
Test Method |
Base Oil |
Synthetic ester |
— |
Thickener |
Complex aluminum |
— |
Appearance |
Yellow uniform grease |
— |
Consistency Number |
1 |
NLGI |
Penetration (0.1 mm) |
310–340 |
GB/T 269-91 |
Operating Temperature (℃) |
-40 to 200 |
— |
Dropping Point (℃) |
>250 |
GB/T 4929-85 |
Evaporation Loss (wt%) |
<1.0 |
GB/T 7325-87 |
Copper Corrosion |
Pass |
GB/T 5096-85 |
Shelf Life (years) |
6 |
— |
