Product Features:
-
Medium damping and cushioning effect, ensuring smooth and precise movement of components.
-
Suitable for mating parts, allowing for larger gaps and tolerances.
-
Provides sealing, preventing water ingress.
-
Fully based on synthetic oils.
Storage Conditions:
-
Store in a cool, dry place, protected from direct sunlight and wind.
-
Do not mix with other greases; strictly avoid contamination with foreign substances.
Packaging Specifications:
-
1 KG/Can (6 KG/Carton)
Limited Warranty Information – Please Read Carefully:
The information provided here is accurate to the best of our knowledge. However, since the conditions and methods of use are beyond our control, this information cannot replace the customer’s own testing to ensure product safety, effectiveness, and suitability for a specific end-use. Any usage recommendations provided must not be construed as infringing on any patents. MSDS/SDS are available from the manufacturer upon request.
Applications:
Knobs of telescopes, microscopes, cameras, measuring instruments, and other optical devices
-
DVD player turntable damping gear and switch mechanisms
-
Washing machine suspension rods and air conditioner adjustment knobs
-
Audio equipment knobs and door/window buffers
-
Gear lubrication and noise reduction in plastic toys
-
Potentiometers, tuners, and capacitor spindle fine adjustments
-
Various dampers, damping wheels, and damping hinges
Technical Parameters of Damping Grease P616 :
Test Item |
Measured Value |
Test Method / Standard |
Appearance |
Colorless, transparent |
Visual Inspection |
Physical State |
Semi-fluid |
— |
Operating Temperature (℃) |
-3 ~ 130 |
— |
Volatility (wt%) |
<0.4 |
GB/T 7325-87 |
Torque Value at 25℃ (Starting Torque, gf·cm) |
75 |
ASTM D1478-80 |
Environmental Certification |
RoHS, REACH, Halogen-free, 19P, EN71 |
— |
Shelf Life (years) |
6 |
— |
